Cavit Scale User Manual

1.   Introduction

Cavit Scale is an app for Apple iPhone or iPad that controls Arabic quartertones on keyboard from various keyboard manufacturers.
The functions are dependent on Cavit editions.
Core features are Arabic quartertones, transpose +/-, octaver up/ down and ribbon controller.

There are 4 product editions. These are Cavit Scale 4SP, Cavit Scale CP, Cavit Scale Premuim Edition, Cavit Scale Ultimate.

2.   Interfaces

Cavit Scale has 2 ways to connect to the keyboard. The first is via Bluetooth the second is via cable. The brand are listed in the following chapters.

The application to be used in conjunction with compatible interfaces.

Do not change the Name of you Bluetooth device.

2.1. Yamaha MD-BT01 Interface (Bluetooth)

This Bluetooth interface is compatible to Cavit Scale app and have to be connected to the midi in and out port at the keyboard.

2.2. Quicco Sound mi.1 Interface (Bluetooth)

This Bluetooth interface is compatible to Cavit Scale app and have to be connected to the midi in and out port at the keyboard.

2.3. Apple Lightning to USB Camera Adapter (Cable)

This Cable interface is compatible to Cavit Scale app and have to be connected to the to the iPhone/iPad Device and the keyboard.

USB Cable A port have to be connected with USB Lightning to Camera Adapter.

USB Cable B port have to be connected with USB-Midi port at the keyboard

You can use following cable:

  • Apple Lightning to USB Camera Adapter
  • Apple Lightning to USB 3 Camera Adapter (with Litghning Power Adapter)

Notice:

Apple Lightning to USB Camera Adapter is compatible with iPhone and iPad.

Lightning to USB 3 Camera Adapter (Cable)  is only compatible with iPad.

3.   Setup

3.1.  Communication Channel Config iPhone/iPad

3.1.1. Cavit Scale 4SP

Press CH Button to open Configuration Dialog. Press to number field to increase the communication channel. On some iPhone/iPad devices the communication channel is 0 or 1.

After channel 5 the number becomes 0. Press PaX-Button to close configuration dialog

3.1.2. Cavit Scale 4CP

Press CH Button to open Configuration Dialog. Press to number field to increase the communication channel. On some iPhone/iPad devices the communication channel is 0 or 1. After channel 5 the number becomes 0. Press Kronos-Button to close configuration dialog

3.1.3. Cavit Scale Premium

Press CH Button to open Configuration Dialog. Press to number field to increase the communication channel. On some iPhone/iPad devices the communication channel is 0 or 1. After channel 5 the number becomes 0. Press Dual-/, Kronos-/ or PaX-Button to close configuration dialog

3.1.4. Cavit Scale Ultimate

  • Press Keyboard 1 or Keykoard 2 to select your Keyboard (do not select it twice as here).
  • Touch to the Default value to setup the Microtuning Default.
  • The Scale Bank Proctektion have to switched be „Off“ to save you Microtuning Scale in Bank 1 to 7.
  • Upper 2&3 option sould switched be „On“ if your Keyboard has sounds on Upper 2&3. If „Upper 2&3 = Off“ Trill/Autopitch options only send on Upper 1.

3.1.5. SWAM Audio Modeling


Cavit Scale Ultimate (with Cavit Scale Version 3.25, SWAM Instrumens Version 3.6.0 and up) supports the the big colletion of SWAM Instruments such as microtuning, transpose, pitchbending on all operating systems supported by SWAM Audiomodeling such as iOS, MacOS and others. For more informations,
please visit Audio Modeling’s website https://audiomodeling.com.

Please check also the following „Cavit Scale Ultimate“ settings for SWAM Instruments:

  • Set SWAM to „Emotion Transpose = On“, if you use Cavit Scale Ultimate Trill/Autopitch options should to transpose. If the conected Keyboard handle tanspose select „Scale Transpose = Off“.
  • Set SWAM to „Scale Transpose = On“ if Cavit Scale app should to transpose it. If the conected Keyboard handle tanspose select „Scale Transpose = Off“. In this case transpose SWAM Instruments and your connected Keyboard via Cavit Scale Instruments.
  • Select „SWAM Scale & Trill“ Channel to enable the side by side communtion between SWAM Instruments and „Cavit Scale Ultimate“.
